Trick question. Voltage alone is not the only contributing factor to the severity of an electric shock. Current, normally measured in amps, is also a critical part of the equation, along with other minor factors.
Voltage is a measure of the pressure or force of the electrical power passing through a conductor, while current is more an indicator of rate of the electrical flow. It’s the flow of current passing through the body that clamps the heart or causes it to fibrillate, potentially resulting in death.
So the question really should be: How much current does it take to kill someone?
The answer is very little. A current of as little as 0.007 amps (7mA) across the heart for three seconds is enough to kill. 0.1 amps (100mA) passing through the body will almost certainly be fatal.
However, the current involved in an electric shock is determined by the voltage and the resistance of the circuit. The human body has an inherent high resistance to electric current, which means without sufficient voltage a dangerous amount of current cannot flow through the body and cause injury or death. As a rough rule of thumb, more than fifty volts is sufficient to drive a potentially lethal current through the body.
Other factors that can determine the severity of an electric shock include the duration of the shock and where the shock enters the body. For example, a shock passing from one arm through the chest to the other arm is much more dangerous than a shock between two toes.
Here’s some examples:
- A static electricity shock can be 20,000 volts or more, but at extremely low current and for an extremely short duration: Harmless
- A 9V battery is at an insufficient voltage to drive a dangerous level of current through the body: Harmless
- A 240VAC power point is at a dangerous voltage and more than capable of driving a very dangerous current: Potentially lethal
- A lightning bolt can be a billion volts and can deliver extremely high current (around 30,000 amps): Potentially lethal
